Thiết bị AP Wifi NAP-1AC là bị không dây được trang bị 2 băng tần kép chuẩn 802.11AC, thiết bị nhỏ gọn, đẹp trang nhã, phù hợp với hộ gia đình, khách sạn, các resort, thiết bị được trang bị nguồn cấp POE thuận tiện trong việc thi công và lăp đặt.
Thông số cơ bản như sau:
| General Specification | |
| Network Standards | IEEE802.11n, IEEE802.11g, IEEE802.11b, IEEE802.11a, IEEE802.11ac Wi-Fi Compliant Dual Band (2.4GHz and 5GHz) Concurrent Operation |
| Wired Network Interface | WAN : 1 Port 10/100/1000Mbps, IEEE802.3af PoE, Auto MDI/MDIX, RJ-45 |
| Frequency Bandwidth | • 802.11b/g/n: 2.4-2.484 GHz • 802.11a/n: 5.15-5.25 GHz; 5.25-5.35 GHz; 5.47-5.725 GHz • 802.11ac: 5.17-5.33 GHz; 5.49-5.725 GHz; 5.735-5.825 GHz (Channel 20/40/80MHz) |
| Media Access Protocol | CSMA/CA |
| Features | |
| RF Features (무선 특징) | • Multiple AP (Additional 4-MultipleAP for Wireless BAND – BAND, SSID 등 설정 가능) • Channel Width Selection (20, 40 and 80MHz) |
| • Auto Channel Selection • SSID Broadcast / Hidden SSID • WMM (Wi-Fi Multi-Media) • RX, TX Wiress Data Rate Restriction • Wireless Client Viewer | • Neighbor Access Point or IBSS Scan • MAC Clone for single Ethernet Client • RF Power Control (5-Levels Power Selection) • WDS (Wireless Distribution Service) |
| Network Features (네트워크 특징) | • Static IP address configuration, DHCP Server/Client • Filtering (Port Number, IP Address & Protocol, MAC Address, URL) • PPPoE (Point-to-Point Protocol over Ethernet) • PPTP (Point-to-Point Tunneling Protocol), L2TP (Layer 2 Tunneling Protocol) |
| • IGMP Proxy • DOS (Denial-of-Service) Prevention • Port Forwarding / DMZ host • NAT (Network Address Translation) | • NTP (Network Time Protocol) • IEEE802.1d Spanning Tree • IEEE802.1Q Tagged VLAN |
| Security (보안 기능) | • Hidden ESSID (SSID 숨김 기능) • 802.1x Authentication (RADIUS) • 64, 128-bit Web Key Encryption • WPA2, WPA-Mixed |
| Management Features (관리 기능) | • Wireless Schedule Rule (사용 시간 제한 기능) • Web based Management (웹 기반 관리 페이지 제공) • SNMPv2c (Simple Network Management Protocol) • Firmware Upgrade (via HTTP / FTP Client) • System Log (Remote Log 서비스 지원) |
| Physical and Operation Specifications | |
| Input Power | IEEE 802.3af PoE ; External PoE Adapter (DC 48V, 0.5A) |
| Operation Temperature | 0 to 40℃ |
| Storage Temperature | -40 to 70℃ |
| Humidity | 10 to 90% non-condensing |
| Dimensions (W x H) | 120 x 120 x 18.80mm |
