A. Imaging Device

1/2.8" 2.38M CMOS

B. Total Pixels

1,952(H) x 1,116(V), 2.18M pixels

C. Effective Pixels

1,944(H) x 1,104(V), 2.14M pixels

D. Scanning System

Progressive

E. Min. Illumination

1. Color

0.3Lux (1/30sec, F1.6, 50IRE),

0.005Lux (2sec, F1.6, 50IRE)

0.1Lux (1/30sec, F1.6, 30IRE),

0.0005Lux (2sec, F1.6, 30IRE)

2. B/W

0Lux (IR LED on)

F. S/N Ratio

50dB

G. Video Output

CVBS : 1.0 Vpp / 75Ω composite,

720 x 480(N), 720 x 576(P), for installation

A. Focal Length (Zoom Ratio)

4.4 ~ 101.2mm (Optical 23x)

B. Max. Aperture Ratio

F1.6(Wide) / F4.5(Tele)

C. Angular Field of View

H : 63.68˚(Wide) ~ 3.1˚(Tele)

V : 37.52˚(Wide) ~ 1.76˚(Tele)

D. Min. Object Distance

1.5m (4.92ft)

E. Focus Control

AF / One-shot AF / Manual

F. Lens Type

DC auto iris (IR corrected)

G, Mount Type

Board-in type

A. Pan Range

360˚ Endless

B. Tilt Range

190˚ (-5˚ ~185˚)

C. Pan/Tilt Speed

Preset : 250˚/sec, Manual : 0.024˚/sec ~ 120˚/sec

D, Sequence Accuracy

Preset (255ea), Swing, Group (6ea), Trace, Tour,

Auto run, Schedule

E. Preset Accuracy

±0.2

F. Azimuth

Yes (E / W / S / N / NE / SE / NW / SW OSD)

G. Auto Tracking

Off/On

A. IR LED

2ea

B. Viewable Length

100m (328.08ft)

C. Camera Title

Off / On (Displayed up to 15 characters)

D. Day & Night

Auto (ICR) / Color / B/W

E. Backlight Compensation

Off / BLC / HLC / WDR

F. Wide Dynamic Range

120dB

G. Contrast Enhancement

SSDR (Samsung Super Dynamic Range) (Off / On)

H. Digital Noise Reduction

SSNRIII (2D+3D noise filter) (Off / On)

I. Digital Image Stabilization

Off / On

J. Defog

Off / Auto / Manual

K. Motion Detection

Off / On (4ea, Rectangular zones)

L. Privacy Masking

Off / On (32ea, Rectangular zones)

- Color : Grey / Green / Red / Blue / Black / White,

- Zoom ratio option for mask mode

M. Gain Control

Off / Low / Medium / High / Manual

N. White Balance

ATW / AWC / Manual / Indoor / Outdoor / Mercury / Sodium

O. Electronic Shutter Speed

Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec)

P. Digital Zoom

16x, area zoom function support digital zoom 2x

Q. Flip / Mirror

Off / On

R. Intelligent Video Analytics

Tampering (Scene change), Virtual line, Enter / Exit, (Dis)Appear,

Audio detection, Face detection

S. Alarm I/O

Input 4ea / Output 3ea (Relay type)

T. Remote Control Interface

RS-485/422

U. RS-485 Protocol

Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon, Bosch, GE

V. Alarm Triggers

Alarm input, Motion detection,

Intelligent video analytics, Network disconnect

W. Alarm Events

File upload via FTP and E-mail

Notification via E-mail

Local storage (SD/SDHC/SDXC) or

NAS recording at event triggers

External output

PTZ preset

A. Ethernet

RJ-45 (10/100BASE-T)

B. Video Compression Format

H.264 (MPEG-4 Part 10/AVC) : Main / Baseline / High, MJPEG

C. Resolution

1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768,

800 x 600, 720 x 576, 640 x 480, 640 x 360,

320 x 240, 320 x 180

D. Max. Framerate

1. H.264

Max. 60fps @ all resolutions

2. MJPEG

Max. 15fps @ 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768

Max. 30fps @ 800 x 600, 720 x 576, 640 x 480,

640 x 360, 320 x 240, 320 x 180

E. Smart Codec

Manual mode (Area-based : 5ea),

Face detection mode

F. Video Quality Adjustment

1. H.264

Compression level, Target bitrate level control

2. MJPEG

Quality level control

G. Bitrate Control Method

1. H.264

CBR or VBR

2. MJPEG

VBR

H. Streaming Capability

Multiple streaming (Up to 10 profiles)

I. Audio In

Selectable (Mic in / Line in),

Supply voltage : 2.5V DC (4mA),

Input impedance : approx. 2K Ohm

J. Audio Out

Line out (3.5mm stereo mini jack),

Max output level : 1 Vrms

K.  Audio Compression Format

G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz,

G.711 8KHz, G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps

L. Audio Communication

Bi-directional audio (2-way)

M. IP

IPv4, IPv6

N. Protocol

TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP,

SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour

O. Security

HTTPS(SSL) login authentication,

Digest login authentication

IP address filtering, User access log,

802.1x authentication (EAP-TLS, EAP-LEAP)

P. Streaming Method

Unicast / Multicast

Q. Max. User Access

15 users at unicast mode

R. Edge Storage

SD/SDHC/SDXC (Up to 128G)

Motion Images recorded in the SD/SDHC/SDXC memory card can be downloaded

NAS (Network Attached Storage),

Local PC for instant recording

S. Application Programming interface

ONVIF profile S, SUNAPI (HTTP API), SVNP 1.2, Samsung Techwin Open Platform

T. Webpage Language

English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese,

Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek, Finnish, Norwegian

U. Web Viewer

1. Supported OS

Windows XP / VISTA / 7 / 8, MAC OS X 10.7

2. Supported Browser

Microsoft Internet Explorer (Ver.8 ~ 11),

Mozilla Firefox (Ver. 9 ~ 19),

Google Chrome (Ver. 15 ~ 25),

Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7) * Mac OS X only

V Central Management Software

SmartViewer, SSM

A. Voltage

24V AC only / 6A

B. Power Consumption

Max. 30W (Heater off)

Max. 35W/90W (Heater off/on, IR on)

A. Operating Temperature / Humidity

-50°C ~ +55°C (-58°F ~ +131°F) / Less than 90% RH

B. Storage Temperature / Humidity

-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH

C. Ingress Protection

IP66

D. Vandal Resistance

IK10

A. Dimension

Ø248.0 x 399.5mm (Ø9.76" x 15.73")

B. Weight

7.1Kg (15.65 lb)

C. Color/Material

Ivory / Aluminum
